Additional information
| Weight | 7.2 kg |
|---|---|
| Dimensions | 192 × 192 × 27 cm |
HWR SOLIDPoint Zero point plate 660205
The HWR SOLIDPoint mechanism is ingeniously simple with 3 moving parts and with the 96 and 52 combination grid in one plate has set a new standard for zero point clamping
Compatible with 45710
£685.80 ex VATAvailable on back-order
Share:
Plate dimension: 192 x 192 x27mm
Zero point system 96 / 52
Zero point stud: 20 / 16 mm
Suitable vice: 125 /77 / 46
Max. tightening torque: 45Nm
Holding force: 60kN
Accuracy: 0.005mm
weight: 7.2kg
Wrench size: 8mm
Centering accuracy: +/- 0.02mm
